Digital oil bath with squared tank 13 lt - WB-OD15
The digital WB-OD 15 oil baths for laboratories with a rectangular tank of 13 liters are devices used to maintain stable and controlled temperatures during experiments and chemical processes. These baths consist of a tank filled with thermal oil, heated by heating elements placed under the tank for easy cleaning. The rectangular shape of the tank provides a larger useful surface area, allowing accommodation of multiple samples or containers simultaneously. The tank and internal casing are entirely made of 18/8 stainless steel.
The tank is insulated with insulating material to minimize heat transmission to the outside. This type of bath is ideal for experiments requiring prolonged or gradual heating and can be equipped with digital thermostats for precise temperature control. Rectangular oil baths are widely used in chemistry, biology, and engineering to ensure consistent and reproducible temperature conditions, particularly useful in applications requiring accurate thermal control over a large surface area.
Unlike water baths, oil baths reach higher temperatures, up to 300°C.
Instrument features:
- The outer structure and tank are made of 18/8 stainless steel sheet metal, formed in a single piece.
- Manual reset safety thermostat with red light alarm indicator.
- PID temperature control with PT100 probe.
Data sheet
Item | 614.1032.15 |
---|---|
Temperature | +5 amb. to +300 |
Precision | +/- 1 |
Heating power | W 1400 |
Internal dimension (LxWxH) | mm 255x290x150 |
External dimension (LxWxH) | mm 445x385x240 |
Power | V/Hz 230/50-60 |
Weight | Kg 6.2 |
Security class | 1 |
Protection class | IP 42 |
Capacity | lt 12 |
Unload + level | Si |
